Nissan Armada 2025-2026 Service and Repair Manual: Feeder Layout
Vehicle Side
Without ProPILOT ASSIST 2.1
Antenna amp.
Window antenna (main)
Roof antenna (satellite)
Window antenna (sub)
Clip with connector (M324)
Clip with connector (M413)
Harness connector (M329)
Harness connector (M414)
Harness connector (M320)
Mounting bolt
: Clip
To inside cabin With ProPILOT ASSIST 2.1
Antenna amp. Window antenna (main) Roof antenna (satellite) Window antenna (sub) Clip with connector (M324) Clip with connector (M413) Harness connector (M329) Harness connector (M414) Harness connector (M320) Mounting bolt : Clip To inside cabin
Inside Cabin
| GPS antenna | | AV control unit | ||
| Harness connector (M323) | | Harness connector (M412) | | Clip with connector (M325) |
| : Clip | ||||
| To vehicle side | ||||
Antenna Feeder
...
