Nissan Armada 2025-2026 Service and Repair Manual: Removal and Installation
CAUTION:
Never bend the fixing pawl of rear armrest.
REMOVAL
Remove rear door finisher. Refer to Removal and Installation.
Disconnect rear power window switch harness connector.
Remove rear armrest fixing screws
, and then remove rear armrest
from rear door finisher
.
 | : Pawl |
Remove rear power window switch from rear armrest .
| : Pawl |
INSTALLATION
Install in the reverse order of removal.
