Nissan Armada 2025-2026 Service and Repair Manual: Feeder Layout

Gps Antenna

...

Removal & Installation

REMOVAL Remove the instrument panel assembly. Refer to Exploded View. Remove the GPS antenna mounting screw , and then remove GPS antenna . INSTALLATION Install in the reverse order of removal. ...
