Nissan Armada 2025-2026 Service and Repair Manual: Removal and Installation
REMOVAL
Remove A/T assembly from the vehicle. Refer to following :
2WD models: Refer to Removal and Installation.
4WD models: Refer to Removal and Installation.
Remove the drive plate using the following procedure:Secure crankshaft pulley
with a pulley holder (A).
CAUTION:
Do not disassemble drive plate.
Do not place drive plate with signal plate facing down.
When handling signal plate, take care not to damage or scratch drive plate and signal plate.
Handle signal plate in a manner that prevents them from becoming magnetized.
Remove the crankshaft position sensor if necessary.
INSTALLATION
Install drive plate , drive plate reinforcement
as shown.
CAUTION:
Be careful not to damage or scratch the drive plate and signal plate.
 | : Crankshaft |
 | : Rounded |
 | : Engine front |
Hand tighten drive plate bolts in a diagonal order over several steps.
Tighten drive plate bolts using a suitable tool in a diagonal order over several steps.
If removed, install the crankshaft position sensor.
Installation of the remaining components is in the reverse order of removal.
CAUTION:
If crankshaft position sensor replaced, perform "ELECTRIC IVT CONTROL ACTUATOR POSITION LEARNING". Refer to Work Procedure
Exploded View
Crankshaft position sensor Dowel pin Drive plate : N·m (kg-m, ft-lb) : N·m (kg-m, in-lb) ...
Inspection
DRIVE PLATE DEFLECTION
Appearance of Drive Plate
Check the drive plate and signal plate for defamation or damage.
CAUTION:
Do not disassemble drive plate.
Do not place drive plate with signal plat ...
