Nissan Armada 2025-2026 Service and Repair Manual: Hydraulic Layout
 | Rear washer tube B |  | Rear washer nozzle |  | Rear washer nozzle tube |
 | Rear washer tube C |  | Rear washer tube A |  | Washer tank assembly |
 | : Clip | ||||
Exploded View
Rear washer nozzle Rear washer nozzle tube Connector Rear washer tube C Grommet Connector Rear washer tube B assembly*1 Rear washer tube A Tube protector Washer tank assembly Intelligent re ...
