Nissan Armada 2025-2026 Service and Repair Manual: Removal and Installation
REMOVAL
Remove the headlining assembly. Refer to Removal and Installation.
Disconnect the antenna feeder connector.
Remove the mounting nut
.
Remove the roof antenna from the vehicle.
INSTALLATION
Note the following, and install in the reverse order of removal.
CAUTION:
Be careful about tightening torque. Antenna sensitivity becomes poor, and when it is excessive, roof panel may be deformed, when roof antenna mounting bolt tightening torque is loose.
Exploded View
Roof antenna : N·m (kg-m, in-lb) ...
