Nissan Armada 2025-2026 Service and Repair Manual: Working Environment
Pay attention to ventilation and the health of workers.
Paint and sealant may generate poisonous gases when heated by fire. To prevent this, do not use a gas welder for cutting off damaged portions.
Use an air saw or an air chisel.
Use a belt sander or rotary wire brush for removing paint from the panel.
Inflammables
Before starting repair work, be sure to disconnect the negative terminal of the battery.
When welding parts near the fuel tank fuel filler, be sure to remove the fuel tank. Plug the filler port of th ...
Handling of Welding Equipment
(1) STORAGE OF GAS CYLINDERS
In a well ventilated area, post a “No Fire” sign.
Avoid the direct rays of the sun. Maintain temperature below 40°C (104°F).
Inflammable gas cylinders and oxygen cy ...
