Nissan Armada 2025-2026 Service and Repair Manual: Removal and Installation
CAUTION:
REMOVAL
Remove instrument pad B. Refer to Removal and Installation.
Disconnect harness connector.
Remove indirect light RH fixing screws
, and then remove indirect light RH.
Disengage advanced ambient light (instrument panel passenger side) fixing pawls using a remover tool (A), and then remove advanced ambient light (instrument panel passenger side).
 | : Pawl |
INSTALLATION
Install in the reverse order of removal.
Exploded View
Instrument finisher B Advanced ambient light (instrument panel passenger side) Indirect light RH : Pawl : Vehicle front ...
Replacement
CAUTION:
Replacement of bulb is not possible due to the adoption of LED. When replacement, replace advanced ambient light (instrument panel passenger side) as a single part. Refer to Removal and Insta ...
